Frigga
4G Temp and RH Online Location Monitor
ALL PRICES DISPLAYED ARE EXCLUSIVE OF VAT.
ACCESSORIES ARE SOLD SEPARATELY.
NOT SURE WHAT TO ORDER? CONTACT US TODAY!
A new generation of global real-time temperature monitoring with a single usage. Data is stored in the cloud for traceability; USB port for backup PDF data download.
Highlighted Features
- Full cold chain visibility(Location, Temperature, Humidity, Light, Shock, Route) via Frigga cloud
- Improve transportation efficiency and reduce products loss with real-time monitoring
- 24/7 data control & analysis, manage quality and control of your products in transit. Real-time alert via SMS, Email, and APP
- Support weak light detection, and protect the safety of your goods effectively
Specifications
Parameters |
Details |
Usage Type |
Single-use(Max 60days) |
Monitor Information |
Temperature, Humidity, Light, Shock, Location, Track routes |
Temperature Sensor |
Internal Texas Instruments (TI) Brand Digital Sensor |
Temperature Measurement Range |
-30°C ~ 70°C ( -22°F ~ 158°F) |
Temperature Accuracy Range |
±0.5°C (-20°C ~ +40°C); ±1°C for other range |
Humidity Measurement Range |
5%~95%RH |
Humidity Accuracy Range |
±3%(20%~80%RH); ±5% for other range |
Resolution(Temperature/Humidity) |
0.1°C / 1%RH |
Light Sensor Range |
0~52,000 Lux, detect whether doors or cartons open |
Memory Capacity |
Max 28800 readings |
Location Type |
LBS Base Station Positioning |
Cellular |
Global LTE 4G/5G, fallback 2G network. |
SIM Card |
Internal Embedded (Global Data Roaming) |
Storage temperature range |
-10°C ~ +55°C |
Use Time |
60 Days use time with 60 Min reporting interval |
Data Logging Interval |
10 Min. (settable via the platform) |
Data Reporting Interval |
10 Min. (10/20/30/60 Min settable via the platform) |
Environmental Rating |
IP64 |
Cold Chain PDF Report |
Get PDF report via USB2.0/ Frigga cloud platform/Frigga Track(Mobile App) |
Dimensions/Weight |
103 x 61.3 x 23 mm / 140 grams |
Certifications |
FCC,CE,RTCA/DO-160G,UN38.3,ROHS,WEEE |
Shelf Time |
12 Months |
