Full Glass pH Meter
ALL PRICES DISPLAYED ARE EXCLUSIVE OF VAT.
ACCESSORIES ARE SOLD SEPARATELY.
NOT SURE WHAT TO ORDER? CONTACT US TODAY!
Full Glass pH Meter
EUCA Head Office
Clearwater Office Park
Parkhaven, Block H Ground Floor
Boksburg
Gauteng
1459
South Africa
The 8693 AZ pH Meter could insert its 13 cm long pH probe to the container with narrow opening size easily than other pH Meter. It has the waterproof IP65 function, and it can measure the pH value from 0~14 to meet different Water Quality Testing applications.
The pH sensor electrode of 8693 AZ Long Tube Full Glass pH Pen is protected/storage in a bottle, which could keep the pH sensor wet. The 8693 AZ Long Tube Full Glass pH Pen can be calibrated easily by one touch calibration function.
Highlighted Features
-
IP65 Waterproof housing
-
13 cm long pH probe
-
Big and clear LCD provide real time pH and Temperature display
-
Dual display with ATC
-
Measuring stability indicator
-
One touch for auto-calibration up to 3 points
-
Calibration values are adjustable
-
Hold function to freeze the current reading
-
Compact size, easy to fit in pocket
-
Low battery indicator
-
Auto power off
-
C/F unit switchable
-
Power by 2 pcs CR2032 batteries
- Storage bottle to keep pH sensor wet & last life time
Applications
The 8693 AZ Long Tube Full Glass pH Pen has big and clear LCD to show the real time pH and temperature value. The glass pH electrode of 8693 AZ can be met with the water solution pH measuring purposes of laboratory, water treated or food treated processing industry testing objects.
Specifications
Model | 8693 |
pH Measuring Range | 0.00~14.00 |
pH Accuracy | ±0.1 |
pH Resolution | 0.01 |
Temperature Measuring Range | 0~80.0℃ |
Temperature Accuracy | ±1℃ |
Temperature Resolution | 0.5℃ |
pH Electrode Material | Glass |
Reference | Single Ag/AgCl |
Junction / Flow Rate | Ceramic |
Electrolyte | Gel. 3.3M KCl |
pH Sensor Tip Shape | Spheric |
pH Probe Diameter | 12 mm |
pH Probe Length | 130 mm |
ATC | ATC |
pH Calibration | Up to 3 points |
LCD Size | 29(L) * 22.5(W) mm |
Operating Temperature | 0~80℃ |
Operating RH% | Humidity <80% |
Storage Temperature | -10~50℃ |
Storage RH% | Humidity <90% |
Sensor Life Time | >6 months (with good maintenance) |
Meter Size | 94(L) * 36(W) * 20(H) mm |
Weight | ~115g |
Battery | CR2032 *2 PCS |
Standard Package | Meter, Batteries, Manual, Paper Box |
